Equipment

Manufacturing Equipment
1.Metal Casting

Casting Machine(8 sets)
Work Characteristics:
1.The casting machine features simple operation process, high production efficiency, which is easy to automate.
2.Casting can replace part of the assembly, which keep less consumption of raw materials, save energy and assembly time.
3.The flow of molten metal in the runner when turning less conducive to play a booster role in enhancing the quality of casting.
4.Cold chamber die casting machine is mainly used for aluminum, magnesium, copper and other alloys.Hot chamber die casting machine is mainly used for zinc, magnesium, lead, tin and other alloys.
5.Casting mechanical performance, exchange of good performance, ease of maintenance are available.
6.Die-casting products with clear outline, thin-walled casting and complex parts&patterns, getting a high definition.
7.High investment casting equipment is generally used for mass production.

2.Metal Fabricator

Forging Press(3sets)
Work Principle and Features:
1.A forging machine is also called a press or punch press, which presses down on a metal blank and creates a specific shape.
2.Operated in one of three common temperatures (cold, warm and hot), the designation is the key to the temperature of the metal being shaped.
3.Using enough pressure to stamp a basic shape from a solid piece of metal in a single strike, the forging machine often operates from a flywheel mechanism that powers a stamping die downward and into the second component piece of the total die, continually pressing due to the inertia of thespinningflywheel.
4.It is a common design trait for a forging machine to drop or press the die or stamp straight down on the work piece, hence the name dropforge.
5.Forged steel and aluminum parts retain greater strength than a cast or machined item due to the grain of the forged material running in the same direction throughout the entire part.
6.This greater strength retention leads to the forging machine being the preferred method of creating high-strength, durable products such as hand tools, machine parts and engine pistons.
7.While the forging machine gives the basic shape to a part by applying severe pressure in a single strike and sandwiching the metal blank between the upper and lower press dies, it often requires several more steps to produce a finished product.


Machining Center (8 sets)
Work Principle:
1.Machining centers is different from the whole CNC machine tools that it can milling, boring , drilling several functions, tapping and thread cutting.
2.It has multiple processes for one device, which can complete the rocessing content once again after clamping the workpiece with its comprehensive and processing ability.
3.It can complete processing of more complex shape, which is used for high precision single parts or small batch production.
Work Features:
1.The workpiece with long process is complicated, which can eliminate human disturbance factors, featuring higher productivity and quality stability.
2.Centralized process is equipped with automatic tool changer, thus clamping a workpiece can be completed after a high-precision requirements of milling, drilling, boring, expanding, reaming, tapping and other complex processing.
3.When an automatic pallet is machining a workpiece, another workpiece can clamping table, which greatly reduce the auxiliary time and improve processing efficiency.
4.The greater the capacity of the knife library, the wider the processing scope and the higher the degree of flexibility of processing.


Vulcanizing Machine (3 sets)
Working Principle:
1.Rubber belt vulcanizing is the process that turn rubber into glue, and in the process pressure and temperature is provided to control the vulcanization of time.
2.Vulcanization machine is to meet this process, in which the rack and water pressure plate provide pressure, control box and heating plate provide temperature and controlled curing time.
3.Rubber is a clay like plastic body, in which the sulfur gas containing certain proportion, and through heating and pressurization, to start chemical reaction under a certain temperature and pressure, becoming elastic rubber after a period of time.


CNC Machine (8 sets)
Working Principle:
1.The relative movement will be required in multiple steps, such as startup and stop of the machine tool and spindle volume speed, workpiece clamping or loosening, tool selection and exchange, cutting fluid of open or closed, etc.
2.Feed rate are numbers of code.Writing parts machining program according to the surname, and then sent to computer numerical, processing and analyzing by control system.
3.After issuing the corresponding command and controlling the servo system or other actuator, automatic machine will processing the workpiece.


Drilling Machine(6 sets)
Working Principle:
1.Machine tool for machining holes on a work piece with a drill bit.Usually, the drill bit rotates in the main motion, and the bit moves axially into the feed motion.
2.Drilling machine has the advantages of simple structure and relatively low machining accuracy.
3.Drill works through holes, blind holes, special replacement tool to expand and reaming holes.


Tapping Machine(4 sets)
Working Principle:
Tapping machine is to work out internal threads, screws or tooth buckle on the hole’s medial surface of the parts, like machine shell, end face, nuts, flange plate with different specifications of the through-hole or blind hole.


Polishing Machine(6 sets)
Working Principle:
1.Motor drive is installed in the polishing machine, and sponge or wool polishing disc rotates with high-speed.
2.Due to the polishing pad and polishing agent make interaction friction with casting surface, which can remove paint pollution, oxidation layer, shallow marks.
3.The speed of the polishing disc is generally in the 1500 to 3000 r/min, most of them are continuously variable speed, the construction can be adjusted at any time according to need.
3.Plastic Molding.


Injection Molding Machine(6 sets)
Working Principle:
1.It uses the screw (or plunger) thrust, putting plastic with a good melting state (viscous flow) injection into the closed mold cavity, after curing and shaping to obtain products.
2.Injection molding is a cycle process, each cycle mainly includes: quantitative feeding, melt plastic, pressure injection, mold filling and cooling.Take out the plastic part and then close the mold, for the next cycle.
